Description
Cast Iron Electrode Cast Ni x 4.0mm x 1Kg
The Cast Iron Electrode Cast Ni is specifically designed for cold welding of grey and malleable cast iron. It is also suitable for joining cast iron with steel. The electrode allows for welding in all positions, including vertical down, ensuring versatility and flexibility in various applications.
Features & Benefits:
- Pure Ni Core Wire: Ensures high-quality welds with excellent properties.
- Versatile Welding: Suitable for welding grey and malleable cast iron and for joining cast iron with steel.
- All-Position Welding: Allows for welding in all positions, including vertical down, offering flexibility in application.
Common Applications:
- Cold welding of grey and malleable cast iron.
- Joining cast iron with steel.
Welding Positions:
Welding Current: AC, DC+
Suitable positions: PA, PB, PC, PE, PF, PG
TYPICAL WELD METAL COMPOSITION
| Element | Composition |
|---|---|
| Ni | 96.0% |
TYPICAL MECHANICAL PROPERTIES
| Property | Value |
|---|---|
| Ult Tensile Strength | > 300 N/mm² |
| Hardness | 160 [HB] |
| Redrying | 200°C / 1h |
Material to be Welded: Grey cast iron, malleable cast iron.
AVAILABLE FORMATS: ELECTRODE RODS (MMA / SMAW)
| Dia | 1.0kg Pkt | Current Range (Amps) | Approx Pcs/KG |
|---|---|---|---|
| 2.5mm | RE5002501 | 60-80 | 2.5 |
| 3.2mm | RE5003201 | 80-110 | 3.2 |
| 4.0mm | RE5004001 | 110-150 | 4.0 |
Standards:
- EN ISO 1071-A
- AWS A5.15
- DIN 8573
