Description
Jasic Tig 200P AC/DC Mini (ZXJT-200DS) with WH04B Helmet
The JASIC TIG 200P AC/DC Mini Inverter Welder is a cutting-edge single-phase inverter power source that offers an ultra-portable welding solution. Designed with an innovative and user-friendly control panel, it features a digital weld cycle, various welding modes, and an autosave memory function that retains settings even after the machine is turned off. Given its technical prowess, it’s a top pick for professional TIG welders seeking precision and reliability.
The JASIC TIG 200P AC/DC Mini Inverter Welder is a compact yet powerful welding solution designed for professionals. With its advanced features and the added benefit of the WH04B Auto Sensing Welding Helmet, it offers both performance and safety. Whether you’re in a workshop or on a job site, this welding machine promises top-tier results every time.
Key Features
- TIG Pulse AC/DC Inverter Welder: Ensures precise and consistent welding performance.
- High Frequency Inverter: Reduces the weight and size of the machine, making it more portable.
- Intelligent Digital Microprocessor Control: Offers advanced control over the welding process.
- Autosave Memory Function: Retains the last used settings even after shutdown.
- Intuitive Control Panel: Easy-to-use interface that allows for quick adjustments.
- Auto Protection Circuits: Enhances the lifespan of the inverter by protecting against potential hazards.
- Advanced Arc Ignition System: Ensures a stable and consistent arc during welding.
- TIG Tungsten Electrode Selection System: Allows the user to choose the best electrode for the job.
- High-Speed Pulse: Provides precise adjustment capabilities for optimal weld bead formation.
- AVR Generator Friendly: Can operate efficiently with AVR generators.
Welding Capacity
- DC Mode: Suitable for welding Steel/Stainless Steel up to 4.8mm (3/16″).
- AC Mode: Ideal for welding Aluminium up to 6.4mm (1/4″).
Package Contents
- TIG inverter welder
- TIG welding torch & adaptor
- Gas regulator
- Earth return lead
- WH04B Auto Sensing Welding Helmet
Technical Data
| Input Voltage | AC 230V – 50/60 Hz |
| Ieff (A) | 16 |
| Input Power (kVA) | 6.9 |
| Current Range (A) | TIG 5 – 200, MMA 10 – 160 |
| Duty Cycle @ 40°C | TIG 200A @ 25%, MMA 160A @ 30% |
| No-Load Voltage (V) | 60 |
| Efficiency (%) | 85 |
| Power Factor | 0.7 |
| Protection/Insulation Class | IP21S/B |
| Dimensions (LxWxH mm) | 435 x 160 x 340 |
| Weight (Kg) | 9 |
Supplied with Auto Sensing Welding Helmet
