Jasic EVO Power Arc 160 MMA/TIG Inverter - 160A - 230V Single Phase (EPA-160)

Jasic EVO Power Arc 160 MMA/TIG Inverter - 160A - 230V Single Phase (EPA-160)

EPA-160 Jasic In Stock Fast Dispatch
Price per unit
£299.00 ex VAT
£358.80 inc VAT
Save %
Was £ ex VAT
PRICE PROMISE
Price Match Available on this Jasic product. Found it cheaper at a UK retailer? Send us the link and we will match the total price, delivery included.
  • 160A IGBT inverter welder for MMA and TIG welding
  • Input 230V AC 50/60 Hz, output 20-160A MMA or 10-160A TIG
  • Includes protective carry case and 3 metre MMA lead set
  • Dimensions 370 x 125 x 255mm, weighs 5.5kg
  • Features intelligent synergic control, Smart Lift TIG, anti-stick, hot start and arc force
or
Secure Payment Methods:
Visa Mastercard Maestro PayPal Google Pay Apple Pay
Trustpilot

A series of technologically advanced IGBT inverter welders based off the Jasic EVO design, with the same rugged, ergonomic looks and enhanced feature list with simple operation, suitable for maintenance and light fabrication from a 230Vac input supply.

A 160A feature packed arc welder complete with a digital display – all supplied in a robust carry case and 3 metre MMA lead set as standard

Features & Benefits

  • Rugged, ergonomic design
  • Intelligent synergic control
  • Smart Lift TIG
  • Anti-stick, adjustable hot start and arc force
  • ABAP: Active Balancing Air Passage
  • Fan on demand
  • Voltage Reduction Device (VRD)
  • Key power electronic component protection
  • Overcurrent and overheat protection
  • Complete with protective case and MMA leads
Input Voltage AC 50/60 Hz, AC 230V
No Load Voltage 62V
Efficiency 85%
Power Factor 0.64
Idle State Power 23W
Dimensions 370 x 125 x 255mm
Weight 5.5Kg
Protection Class IP23S
Insulation Class H
Recommended Generator Size 11.5kVA (Generator must have AVR)
Current Range 20-160A
Rated Duty Cycle @ 40ºC 20%
Ieff 14.8A
Rated Input Power 7.6kVA
Current Range 10-160A
Rated Duty Cycle @ 40ºC 20%
Ieff 10.7A
Rated Input Power 5.5kVA
Protective Carry Case Included
MMA 3m Leads Included
Cooling Air Cooled
Pulse Welding Non-Pulse
Power Source Workshop 230V/240V (Single-Phase)
Applications General Fabrication (160-210A)
Duty Rating Light Duty (<30%)
Portability Ultra-Portable
Enclosure Rating IP23 / IP23S or higher
Ignition Type Lift
MMA Duty Cycle 20% at 160A
TIG Duty Cycle 20% at 160A
Brand Jasic
Input Voltage 230V
Amperage 160A
MIG Duty Cycle 25% Duty Cycle
Welding Process MMA, TIG

Datasheet

Download PDF

Product Datasheet

Download PDF

User Manual

Download PDF
