Jasic Evo MIG 350C Compact Package 400V 3-Phase MIG/MAG, MMA and DC Lift-TIG Inverter Welder 350A

Transform your welding projects with the EVO MIG 350 Compact, engineered for professionals who demand precision without compromise. This powerhouse 3-phase welder combines cutting-edge inverter technology with ARM and DSP digital microprocessor control, delivering consistently smooth arc characteristics that make even the most challenging materials feel effortless to work with. The rugged, ergonomic design withstands the demands of daily workshop use while reducing operator fatigue during extended sessions.

Experience unmatched versatility with synergic/manual MIG/MAG, MMA, and DC Lift-TIG capabilities all in one compact unit. The ClearVision HD digital display paired with hollow rotary shaft encoders puts precise parameter control at your fingertips, while the enhanced dual drive wire feeder with 37.45mm rollers ensures consistent wire delivery for professional-quality results every time. Whether you’re running standard MIG, push-pull, or a spool gun torch, this welder adapts to your workflow seamlessly.

Built for the modern workshop, the EVO MIG 350 leads the industry in energy efficiency with on-demand cooling and auto sleep mode that drops idle consumption to less than 10W. Control your welding from anywhere with flexible remote solutions including wired, wireless, and mobile app connectivity, while the USB Type-C port keeps your software updated and devices charged. With convenient program memory storage, and generator-friendly operation, this welder delivers professional performance wherever your work takes you.

Peace of mind comes standard with IP23S protection against harsh workshop conditions and a comprehensive 5-year warranty that backs every weld.

Package Includes: MIG/Multi Process Inverter Power Source, Dual Drive System (4 Roll), Trolley, Hard Core MIG Torch 4m, Feedrolls, Regulator, Gas Hose & Earth Lead

Technical Specifications

• Input Voltage AC 400V,50/60 Hz
• No Load Voltage 76V
• Efficiency >80%
• Power Factor 0.94
• Idle State Power 10W
• Protection Class IP23S
• Insulation Class H
• Dimensions LxWxH 1000 x 530 x 933mm
• Weight 45.1kg
• Recommended Generator Size 22.5kVA
• *Generator must have AVR

MIG Welding Specifications

• Rated input current 21.9A
• Leff 13A
• Rated Input Power 15.2kVA
• Current Range 30-350A
• Rated Duty Cycle @ 40ºC 40%
• Wire Feed Speed 2-24m/min
• Spool Size D300

MMA Welding Specifications

• Rated input current 21.7A
• Leff 13.7A
• Rated Input Power 15kVA
• Current Range 20-350A
• Rated duty cycle @ 40ºC 40%

TIG Welding Specifications

• Rated input current 16.1A
• Leff 10.2A
• Rated Input Power 11.2kVA
• Current Range 20-350A
• Rated duty cycle @ 40ºC 40%
